CHAPTER 15 COMMUNICATION SYSTEMS
- 15.1 Introduction
- 15.2 Elements of a Communication System
- 15.3 Basic Terminology Used in Electronic Communication Systems
- 15.4 Bandwidth of Signals
- 15.5 Bandwidth of Transmission Medium
- 15.6 Propagation of Electromagnetic Waves
- 15.7 Modulation and its Necessity
- 15.8 Amplitude Modulation
- 15.9 Production of Amplitude Modulated Wave
- 15.10 Detection of Amplitude Modulated Wave
NCERT Solutions class 12 physics Communication System
1: Which of the following frequencies will be suitable for beyond-the-horizon communication using sky waves?
(a) 10 kHz
(b) 10 MHz
(c) 1 GHz
(d) 1000 GHz
2: Frequencies in the UHF range normally propagate by means of:
(a) Ground waves.
(b) Sky waves.
(c) Surface waves.
(d) Space waves.
3: Digital signals
(i) Do not provide a continuous set of values,
(ii) Represent values as discrete steps,
(iii) Can utilize binary system, and
(iv) Can utilize decimal as well as binary systems.
Which of the above statements are true?
(a) (i) and (ii) only
(b) (ii) and (iii) only
(c) (i), (ii) and (iii) but not (iv)
(d) All of (i), (ii), (iii) and (iv).
4: Is it necessary for a transmitting antenna to be at the same height as that of the receiving antenna for line-of-sight communication? A TV transmitting antenna is 81m tall. How much service area can it cover if the receiving antenna is at the ground level?
5: A carrier wave of peak voltage 12 V is used to transmit a message signal. What should be the peak voltage of the modulating signal in order to have a modulation index of 75%?
6: A modulating signal is a square wave, as shown in Fig. 15.14.
The carrier wave is given by
(i) Sketch the amplitude modulated waveform
(ii) What is the modulation index?
7: For an amplitude modulated wave, the maximum amplitude is found to be 10 V while the minimum amplitude is found to be 2 V. Determine the modulation index
. What would be the value of if the minimum amplitude is zero volt?
8: Due to economic reasons, only the upper sideband of an AM wave is transmitted, but at the receiving station, there is a facility for generating the carrier. Show that if a device is available which can multiply two signals, then it is possible to recover the modulating signal at the receiver station.
